川消講解消防軟管卷盤的設定范圍與設置要求
來源：http://www.guizhouhuli.net/ 日期：2022-05-19
什么是消防軟管卷盤？根據現行標準《消防軟管卷盤》（GB15090-2005），消防軟管卷盤由閥門、輸入管道、卷盤、軟管和噴槍等組成，在滅火過程中可以快速展開軟管?chē)娚錅缁饎┑臏缁鹧b置。
What is a fire hose reel? According to the current national standard fire hose reel (gb15090-2005), the fire hose reel is composed of valve, input pipe, reel, hose and spray gun. In the process of fire extinguishing, the fire extinguishing device of hose spraying fire extinguishing agent can be quickly deployed.
消防軟管卷盤的型號編制應符合下列規定，例：滅火劑為水，額定工作壓力0.8MPa，軟管內徑19mm，軟管長度25m。軟管卷盤，型號為：JPS0.8-19/25。
The model compilation of fire hose reel shall comply with the following provisions, for example: the fire extinguishing agent is water, the rated working pressure is 0.8MPa, the inner diameter of hose is 19mm, and the length of hose is 25m. Hose reel, model: jps0 8-19/25。
設定范圍
Set range
1、下列建筑物或場所，不得設置室內消火栓系統，但應設置消防軟管卷盤或手提式消防水帶：
1. Indoor fire hydrant system shall not be set in the following buildings or places, but fire hose reel or portable fire hose shall be set:
1）單層、多層的D、E級車間（倉庫），耐火等級為一、二級及以下可燃物。
1) Single layer and multi-layer D and E-class workshops (warehouses), with fire resistance rating of class I, II and below combustibles.
2)耐火等級三、四級，建筑體積不超過3000m?的D類廠房；防火等級為三、四級，建筑體積不超過5000m?的E類車間（倉庫）。
2) The fire resistance rating is grade III and IV, and the building volume does not exceed 3000m? Class D plant; The fire rating is grade III and IV, and the building volume does not exceed 5000m? Class E workshop (warehouse).
3）糧倉、金庫、遠離城鎮、無人看管的獨立建筑。
3) Granaries, vaults, independent buildings far from towns and unattended.
4)建筑物與水接觸會(huì )引起燃燒和爆炸。
4) Buildings in contact with water can cause combustion and explosion.
5）室內無生產和生活供水管道，室外消防用水取自蓄水池等建筑容積不超過5000m?的建筑物。
5) There are no production and domestic water supply pipelines indoors, and the outdoor fire water is taken from reservoirs and other buildings with a volume of no more than 5000m? Buildings.
2.人口密集的公共建筑、建筑高度大于100m的建筑物、建筑面積大于200㎡的商業服務網點，應安裝消防軟管卷盤或便攜式消防水帶。
2. Fire hose reels or portable fire hoses shall be installed in densely populated public buildings, buildings with a building height of more than 100m and commercial service outlets with a building area of more than 200 m2.
3、高層住宅室內應配備手提式消防水帶。
3. Portable fire hose shall be equipped in the room of high-rise residence.
4、養老設施內應安裝直接與室內供水系統相連的消防軟管卷盤，消防軟管卷盤之間的距離不應大于30.0m。
4. Fire hose reels directly connected to the indoor water supply system shall be installed in the elderly care facilities, and the distance between fire hose reels shall not be greater than 30.0m.
5、DN65的消火栓應在步行街兩側商鋪外每隔30m設置一次，并應配備消防軟管卷盤或消防水帶。店鋪應設置自動噴水滅火系統和火災自動報警系統，每個走廊應設置自動噴水滅火系統。
5. DN65 fire hydrant shall be set every 30m outside the shops on both sides of the pedestrian street, and shall be equipped with fire hose reel or fire hose. The shop shall be equipped with automatic sprinkler system and automatic fire alarm system, and each corridor shall be equipped with automatic sprinkler system.
設置要求
Setting requirements
1、可與室內消火栓同箱安裝。
1. It can be installed in the same box as the indoor fire hydrant.
2、消防軟管卷盤應配備內徑不小于ф19的消防水帶，其長度宜為30.0m；手提式水帶應配備公稱直徑為25的內襯消防水帶，長度為30.0m。
2. The fire hose reel shall be equipped with an inner diameter of not less than ф 19. The length of fire hose should be 30.0m; Portable hose shall be equipped with lined fire hose with nominal diameter of 25 and length of 30.0m.
3、消防軟管卷盤和手提水帶應配備等效噴嘴直徑為6mm的消防水槍。
3. Fire hose reel and portable hose shall be equipped with fire water gun with equivalent nozzle diameter of 6mm.
That's enough for Chuanxiao to explain the setting range and setting requirements of fire hose reel. If you want to know more, please pay attention to our website www.cx-fire Com!
